| Pick-Up
Device (size & type)
|
2/3-inch
3-CCD |
| Picture
Elements (pixels) |
520,000 |
| Quantization |
12-bit |
| Signal
Processing |
18
MHz, 36 MHz |
| Sensitivity |
F
13.0 at 2000, 89.9% reflect |
| Minimum
Illumination |
0.01
lux (F 1.4, +48dB +20dB gain) |
| Horizontal
Resolution |
750
lines (center) |
| Aspect
Ratio |
4:3/16:9
switchable |
| Lens |
Interchangeable,
2/3" bayonet mount (optional) |
| Focus |
Manual,
Focus Assist with Digital Zoom |
| Media
Format |
DVCPRO
(medium) |
| Recording
Format |
DVCPRO
50/25 switchable |
| Frame
Rates |
60i,
30P, 24P, 24P Advanced |
| Shutter
Speeds (sec.) |
1/100,
1/120, 1/250, 1/500, 1/1000, 1/2000 |
| Slow
Shutter Speeds (sec.) |
In
Digital Super Gain: 1/6, 1/15, 1/30 |
| Synchro-Scan
Shutter (sec.) |
1/60.3
to 1/250.0 |
| CineSwitch
Technology |
Yes |
| CineGamma
Software |
Yes |
| Assignable
Scene Files |
Yes |
| Programmable
User Buttons |
3 |
| Filter
Wheels |
Dual-stage |
| White
Balance Selection |
2
manual, 1 preset |
| Super
Iris |
Yes |
| Gain
Selection (dB) |
-3,
0, +3, +6, +9, +12, 15, +18, +21, +24, +27, +30; Super Gain: +30,
+36, +42, +48; Digital Super Gain: +6, +12, +20 |
| Color
Matrix |
Adjustable
A+B, color correction |
| SMPTE
Color Bar Generator |
Yes |
| SDI
Terminal |
Optional |
| IEEE
1394 Interface |
No |
| SD
Memory Card Slot |
Yes |
| Multimedia
Card Slot |
No |
| LCD
Screen |
No |
| Viewfinder |
1.5",
2.0", 5.0" (optional) |
| • |
|
Three
2/3" 520,000 Progressive CCD imagers |
|
| • |
|
24P/30P/60i
recording capability |
|
| • |
|
Captures
film-like 24-frame images using CineGamma |
|
| • |
|
50
Mbps DVCPRO50 3.3:1 compression/25Mbps DVCPRO 5:1
compression switchable |
|
| • |
|
Switchable
16:9/4:3 aspect ratios |
|
| • |
|
12-bit
DSP (6 pole matrix, 12 pole color correction) |
|
| • |
|
18MHz
sampling frequency |
|
| • |
|
Dual
Stage Filter Wheel |
|
| • |
|
High
Sensitivity: F13 at 2000 Lux |
|
| • |
|
Minimum
illumination: .11 Lux at +48dB gain |
|
| • |
|
Shutter
speeds and Synchro-scan shutter |
|
| • |
|
Wireless
microphone receiver pocket built-in |
|
| • |
|
4-channel
digital audio recording |
|
| • |
|
SD
Memory Card for scene file swapping |
|
| • |
|
Three
User Programmable buttons for such capabilities as:
Luminance, Reference, Digital Zoom, Black Stretch,
Digital Gain, Channel 1 or 2 Front Volume Control or
Auto Trace White Balance |
|
| • |
|
Remote
control using simple AJ-EC3, Studio RCU with 26 pin
adapter or Digital Triax |
|
| • |
|
Ideal
for program production, independent filmmaking and
content creation |
|
| • |
|
Pre-Recording
Board option offers 15 second caching or single frame
intervalometer |
|
| • |
|
SDI
Option allows for Digital Monitoring |
|
| • |
|
GPS
Option places camera location coordinates in MetaData |
|
|
 |
