Technical
Specifications
|
|
Frequency
Response: |
10Hz -100 kHz,
+0/-1dB |
Dynamic
Range: |
>
116 dB (120 dB bypass) |
THD: |
< 0.015% @
1kHz, 0 dBu |
Input: |
Balanced
XLR 20 KOhm, max. +22 dBu
Unbalanced Jack 1 MOhm, max. +6 dBu
|
Output: |
Balanced XLR
50 Ohm, max. +27 dBu
Unbalanced Jack 50 Ohm, max. +21 dBu
|
PPM: |
5
LED Peak Programme Metering |
Input
Gain: |
±20 dB, Jack
input +15 dB |
Output
Gain: |
0
dB to mute |
Equalizer
Filters: |
Boost/Cut ±20
dB
Symmetrical boost/cut Bandwidth 0.1 to 2 octave
Range 1: 20-2,000 Hz
Range 2: 50-5,000 Hz
Range 3: 100-10,000 Hz
Range 4: 200-20,000 Hz
|
Power: |
Voltage
Selector: 100-120 or 220-240 V, 50-60 Hz IEC mains connector,
External fuseholder |
On: |
Lights up
when unit is powered, stronger when equalizer section is switched on |
Input
Gain: |
Adjusts
sensitivity at input by +/-20dB |
Output
Level: |
From +6dB to
minus infinity |
EQ
Match: |
Level
control of equalized signal |
PPM
Indicator: |
Indicates
available headroom before clipping |
EQ
Bypass: |
Equalizer
bypass |
Center: |
Picks
frequency-band for correction. Marking in kHz |
Bandwidth: |
Controls
broadness of affected band. Scaling in octaves |
Function: |
Boost,
neutral, cut level control |
Overload: |
Indicates
overload |
Dimensions
(WxHxD): |
482x44x185 mm.
19" x 1.75" x 7.3" |
Net.
Weight: |
2.7
Kgs/6 Lbs |
Shipping
Weight: |
3.5 Kgs/7.7
Lbs |
Environment: |
Operating
0 C to 50 C
Storage -20 C to 60 C |
Finish: |
Black
anodized aluminum faceplate |
