| Model |
AIR 6 |
| General |
- |
| System |
2 way
active NearField Monitor |
| Total
Frequency response |
40 Hz
– 22 kHz / 33 Hz – 22 kHz : +/- 3dB |
| Max SPL
1m, pair (IEC short term) |
128 dB
peak / 128 dB peak |
| Max SPL
2m, 5.1 (IEC short term) |
126 dB
peak / 126 dB peak (no LFE ) |
| Precision
of Monitor matching |
+/-
0.2 dB |
| Port
tuning frequency |
45 Hz |
| Internal
Cabinet volume |
12.1
liters |
| Bass
principle |
Bass
reflex |
| Crossover
frequency |
2150
Hz (DSP generated) |
| Crossover
slope |
24dB/oct
(Linkwitz Riley, DSP generated) |
| Tweeter |
Esotec
28mm / 1.1" soft dome, rear chamber, magnetic fluid, 4 mm
die-cast alu front, pure aluwire voice coil |
| Woofer |
175mm
/ 6.5" one-piece molded polyprop dome, 75mm / 3" pure
alu voice coil |
| Mains
voltage |
100 to
240 VAC, 50 to 60 Hz (auto-select) |
| Power
consumtion |
Idle:
50W / Max: 375W |
| Finish |
- |
| Amp: |
Black
anodized alu back plate |
| Cabinet |
Dark
gray MDF baffle, Silver foil |
| Dimensions
(HxWxD) |
338x216x345mm |
| Weight |
Depth
incl. amp & driver: 382mm, 9.8kg |
| Amplifier |
- |
| Tweeter |
Separate
200W PWM amp |
| Woofer |
Separate
200W PWM amp |
| System
sample rates |
- |
| Internal
sample rate |
96 kHz |
| External
sample rate |
31-97
kHz |
| AIR
Masters only |
- |
| I/O
Connectors |
XLR (2
channels AES/EBU in) 3 x RJ 45 proprietary TC Link |
| Formats |
AES/EBU
(24 bit) |
| Word
clock input |
BNC,
75ohm, 0.6-10 Vpp |
| Display |
2 x 16
character dot matrix |
| Operation |
Menu
system / Four bottoms |
| Analog
Input options |
- |
| Input
connectors |
XLR
balanced (pin 2+, pin 3-) |
| Impedance |
10/3
kohm (Balanced/Unbalanced) |
| Selectable
Full scale Input level |
+9,
+15, +21, +27 dBu |
| Dynamic
range |
>
113 dB typ. (Unwighted), BW: 20-22kHz |
| THD+N |
<
-105 dB typ. @ 1 kHz, -3 dBFS |
| Crosstalk |
<
-120 dB, 20Hz to 20kHz |
| A to D
Conversion |
24 bit
(dual bit delta sigma sampling @ 4.1/5.6/6.1/6.1 MHz) |
| <AIR
Slaves only |
- |
| I/O
Connectors |
2 x RJ
45 proprietary TC Link |
| EMC |
- |
| Complies
with |
EN
55103-1 and EN 55103-2, FCC part 15 class B, CISPR 22 class B |
| Safety |
- |
| Certified
to |
IEC
60065, EN 60065, UL 6500, & CSA E60065, CSA File# LR 108093 |
| Enviroment |
- |
| Operating
temperature |
32° F
to 122° F (0° C to 50° C) |
| Storage
temperature |
-22°
F to 167° F (-30° C to 70° C) |
| Humidity |
Max
90% non-condensing |
