FEATURES
• Sample rates: 44.1 kHz, 48kHz, 88.2kHz,
or 96kHz
• Dither outputs to 16, 20, or 24 bits using TPDF or SNR2 algorithms
• 48 bit internal signal path
• Type IV® A/D Conversion System
• Sync input/output
• 2 user-selectable noise shape algorithms
• Gold-plated Neutrik® AES/EBU and S/PDIF connectors
• For use with dbx 160S, 160SL or 786
704X Specs:
| A/D
Conversion: |
24 bit, dbx
Type IV™ Conversion System |
| Converter
Dynamic Range: |
114 dB
unweighted, 22 kHz bandwidth, Type IV™ engaged |
| 117 dB "A"
weighted, 22 kHz bandwidth, Type IV™ engaged |
| Type IV™
Dynamic Range: |
Up to 127dB
with transient material, A-weighted, 22-kHz bandwidth |
| THD+Noise: |
<0.002%
typical at -21.5dBFS, 1 kHz |
| Frequency
Response: |
20 Hz to 20
kHz, +0/-0.5 dB |
| Interchannel
Crosstalk: |
<95 dB at
1kHz |
| Sync Input
Lock Range: |
41.7 kHz to
49.9 kHz |
|
83.4 kHz to
99.8 kHz |
| NOTE:
+4dBU= -21.5dBFS |
|
|
