Video Format:

NTSC or PAL

Video Inputs:

1 Camera Inputs with Loop Through, 1 Vp-p, 75 Ohm

Video Output:

1 Video Output, 1 Vp-p at 75 Ohm

Video Compression:

M-JPEG

Video Resolution:

720 x 484 (NTSC) ; 720 x 576 (PAL)

Compact Flash Memory:

Yes, Built-In Compact Flash Card Slot

Alarm Input:

Yes

Alarm Output:

Yes

Video Display:

Full, PiP, Quad, & 2x2 Zoom for Live & Playback

Audio:

2 Inputs; 2 Outputs

Video Loss Detection:

Yes

RS-232:

9-pin Female Connector

Event Log:

Yes

Hard Disk Storage:

2.5’’ IDE Hot Swappable Hard Drive

Recording Mode:

Continuous time-lapse recording, Timer or Event Recording

Recording Rate:

0.2~60 IPS (NTSC); 0.1~50 IPS (PAL)

Playback Rate:

0.2~60 IPS (NTSC); 0.1~50 IPS (PAL)

Playback Search:

By Date/Time, Event, or Segment

Setup:

On-Screen Display

User Interface:

Menu Driven

User Input Device:

Front Panel Keypad

Timer:

Built-in Real Time Clock

Watch Dog Timer:

Yes

Power Source:

12V DC + 10%, Max DC 5 Amp

Power Consumption:

60 W max

Operating Shock:

8G, 11ms (20 per 5 sec max)

Operating Vibration:

5~20 Hz, 0.037 inches (double amplitude)

Operating Temperature:

0°C ~ +50°C

Dimensions:

320.8 (L) mm x 273 (W) mm x 109.9 (H) mm

Weight:

4.7 Kg
