Beta

Cartoni

The BETA fluid damping system is activated vertically and horizontally by two patented CARTONI labyrinth modules providing 3 levels of progressive intensity as well as "0" for freewheeling and whip pans.

Their fully sealed leakproof mechanism features a series of concentric vertical rings separated by a high density fluid component ensuring smooth and precise pan and tilt movements.

The CARTONI Beta is equipped with a 100 mm ball base, telescopic pan bar and quick-release camera plate. A second pan bar is available as an option

Load capacity (150 mm c.g.) : 10 Kg (22 lbs)
Head weight : 2.6 Kg (5.7 lbs)
Pan range : 360º
Tilt range : - 50º / +60º
Ball base diameter : 100 mm
Temp range (ºC) : - 30ºC/+ 60ºC(-22°/+158° F)
Fluid drag : 3 tilt + 3 pan
Counterbalancing : 3 settings + 0
