| Processor |
2.66GHz Quad-Core Intel
Xeon |
Two 2.26GHz Quad-Core
Intel Xeon |
| Cache |
8MB fully shared L3
cache |
8MB fully shared L3
cache per processor |
| Memory |
3GB (three 1GB DIMMs) of
1066MHz DDR3 ECC SDRAM |
6GB (six 1GB DIMMs) of
1066MHz DDR3 ECC SDRAM |
| PCI Express 2.0 graphics |
NVIDIA
GeForce GT 120 with 512MB GDDR3 memory, Mini DisplayPort and
dual-link DVI video output |
| Hard disk drive |
640GB Serial
ATA (3Gb/s); 7200 rpm |
| Optical drive |
18x
SuperDrive with double-layer support (DVD±R DL/DVD±RW/CD-RW) |
| Wireless |
Built-in
Bluetooth 2.1 + EDR (Enhanced Data Rate) |
| PCI Express |
Three open
full-length PCI Express 2.0 expansion slots with mechanical
support for 16-lane cards; 300W combined maximum for all PCI
Express slots |
| Build-to-Order Options |
- 2.93GHz Quad-Core Intel Xeon
- 6GB memory (three 2GB DIMMs)
- 8GB memory (four 2GB DIMMs)
- ATI Radeon HD 4870 with 512MB
GDDR5
- Two NVIDIA GeForce GT 120
- Three NVIDIA GeForce GT 120
- Four NVIDIA GeForce GT 120
- Hard drive bays 1-4: 640GB
Serial ATA 3Gb/s (7200 rpm) or 1TB Serial ATA 3Gb/s (7200 rpm)3
- Mac Pro RAID Card
- Two 18x SuperDrive optical
drives
- AirPort Extreme Wi-Fi card with
802.11n2
- Apple Keyboard
- Apple Wireless Keyboard
- Wireless Mighty Mouse
- Dual-Channel 4Gb Fibre Channel
card
- Quad-Channel 4Gb Fibre Channel
card
|
- Two 2.66GHz Quad-Core Intel Xeon
- Two 2.93GHz Quad-Core Intel Xeon
- 8GB memory (four 2GB DIMMs)
- 12GB memory (six 2GB DIMMs)
- 16GB memory (eight 2GB DIMMs)
- 32GB memory (eight 4GB DIMMs)
- ATI Radeon HD 4870 with 512MB
GDDR5
- Two NVIDIA GeForce GT 120
- Three NVIDIA GeForce GT 120
- Four NVIDIA GeForce GT 120
- Hard drive bays 1-4: 640GB
Serial ATA 3Gb/s (7200 rpm) or 1TB Serial ATA 3Gb/s (7200 rpm)3
- Mac Pro RAID Card
- Two 18x SuperDrive optical
drives
- AirPort Extreme Wi-Fi card with
802.11n2
- Apple Keyboard
- Apple Wireless Keyboard
- Wireless Mighty Mouse
- Dual-Channel 4Gb Fibre Channel
card
- Quad-Channel 4Gb Fibre Channel
card
|
